LIGHTING DISTRIBUTION PANEL (LDP)
Electrical L.T Panel
Connect With Us
The Thermonic Lighting Distribution Panel (LDP) is designed to efficiently distribute electrical power for lighting circuits across industrial, commercial, and residential installations. It ensures safe, reliable, and organized power distribution, incorporating high-quality switchgear components for complete circuit protection.
Thermonic LDPs are engineered to handle varying load conditions, providing overload, short-circuit, and earth-fault protection. Built with precision wiring, phase balancing, and durable enclosures, they guarantee long-term performance and operator safety — suitable for both indoor and outdoor applications.
Thermonic LDPs are designed and tested in accordance with national and international standards:
- 🌐 IEC 61439 / IS 8623 – Low-Voltage Switchgear Assemblies
- ⚙️ IS 13947 / IEC 60947 – Switchgear & Controlgear Standards
- 🇮🇳 IS 3043 – Earthing and Grounding Guidelines
- 🔰 ISO 9001:2015 – Certified Manufacturing Quality
✅ All panels comply with CE and IS electrical safety norms for lighting and power distribution.
Thermonic LDPs are suitable for a wide range of lighting applications in all types of facilities:
- 🏭 Industrial Buildings & Factories – Centralized lighting control and protection.
- 🏢 Commercial Complexes & Offices – Lighting load management with MCB/MCCB feeders.
- 🏗 Warehouses & Infrastructure Projects – Distribution of lighting in large facilities.
- 🌇 Residential & Apartment Blocks – Compact and aesthetic lighting control.
- 🛣 Outdoor Installations & Street Lighting – IP65 enclosures for weather protection.
🔥 Thermonic LDPs ensure efficient, safe, and flexible lighting distribution for all environments.
Each Lighting Distribution Panel is thoroughly tested before dispatch for quality and reliability.
✅ Routine Tests:
- 🔍 Visual & Dimensional Inspection
- ⚙️ Functional Test of Incoming & Outgoing Circuits
- 🚨 Overload, Short-Circuit & Earth-Fault Verification
- ⚡ Insulation Resistance & Dielectric Strength Test
✅ Special Tests (on Request):
- 🌡 Temperature Rise & Load Distribution Test
- 🧭 Endurance Test for Switching Devices
📑 Documentation & Certificates:
- 📄 Test & Inspection Reports
- 🎯 Calibration Certificates
- 🏗 IS / IEC Compliance Certificates
Thermonic LDPs are built with modern aesthetics, high durability, and easy maintenance — combining performance with safety and design precision.
🧾 Documents Shared with Client (Before Production):
- 📐 GA Drawing – Panel layout with incoming/outgoing feeders
- 🔌 SLD – Distribution arrangement for lighting circuits
- ⚙️ BOM – MCBs, MCCBs, Busbars, Indicators, Relays
- 📘 Technical Notes – Load calculation & wiring standards
- 🧠 Control Scheme – Single / Three-phase lighting control logic
💡 Thermonic Advantages:
- ⚡ Compact and modular design for easy expansion
- 🚨 Premium quality copper/aluminum busbars for efficient current flow
- 🔗 Integration with timers, sensors, and energy meters
- 🔥 Robust CRCA / SS enclosures with long-life powder coating
Thermonic LDPs can be customized to meet project-specific lighting distribution requirements:
- ⚙️ Rating Range – 10 A – 800 A (Customizable).
- 🔌 Incoming Supply – 3-Phase, 4-Wire, 415 V AC / 1-Phase 230 V AC.
- 🧭 Protection Devices – MCB / MCCB / ELCB / RCCB / SPD.
- 🚨 Indications – R-Y-B Phase, ON/OFF, Trip, Fault.
- 🏗 Enclosures – CRCA powder-coated IP42/IP54/IP65; SS available on request.
- 🔗 Integration – Timer, DALI, Motion Sensor, or Smart Lighting Controls.
🔥 Thermonic Lighting Distribution Panels provide efficient energy management, aesthetic design, and superior protection for modern electrical systems.
