Thermonic Fire Hydrant Panels comply with the latest international and Indian fire-safety & electrical design standards, ensuring reliability and performance.

• 🌐 NFPA 20 – Standard for Installation of Fire Pumps
• 🇮🇳 IS 12469 / IS 13947 – Standards for Fire Pump Controllers & Switchgear
• ⚙️ IEC 61439 / IS 8623 – Low-voltage switchgear assemblies
• 🔰 TAC / UL / FM Compliance – Fire-safety approvals (on request)
• 💡 ISO 9001:2015 – Certified Quality Management System

✅ Every panel is factory-tested for mechanical integrity, insulation strength, and functional accuracy before dispatch.

Each Fire Hydrant Star-Delta Panel undergoes rigorous factory inspection and quality assurance tests.

✅ Routine Tests:

• 🔍 Visual & Dimensional Inspection
• ⚙️ Functional Test for Auto / Manual Operation
• 🔄 Pressure-Switch Simulation Test
• 🚨 Verification of Star–Delta Transition
• ⚡ Insulation Resistance & High-Voltage Test

🧪 Special Tests (on Request):

• 🌡 Endurance & Performance Test under Simulated Fire Load
• 🧭 Control Circuit Reliability Test

📑 Documentation & Certificates:

• 📄 Routine & Type Test Reports
• 🎯 Calibration Certificates

Thermonic ensures transparent design, documentation, and client approval before manufacturing — providing unmatched confidence and precision.

🧾 Documents Shared with Client (Before Production):

• 📐 GA Drawing – Star-Delta wiring layout and pump control scheme
• 🔌 SLD – Electrical interlocking and control circuit
• ⚙️ BOM – Switchgear, timers, contactors, relays, and wiring materials
• 📘 Technical Notes – Operating logic and NFPA guidelines
• 🧠 Control Scheme – Auto/Manual with pressure-switch auto start

💡 Thermonic Advantages:

• ⚡ Soft-starting via Star-Delta transition for longer motor life
• 🚨 Inbuilt protections against overload, single phasing, and phase reversal
• 🔗 Compatible with Fire Alarm / SCADA integration
• 🔥 Robust CRCA construction with long-life components

Thermonic Fire Hydrant Star-Delta Panels can be customized based on pump capacity and site requirements.

• ⚙️ Pump Rating – Up to 200 HP (Star-Delta Starter).
• 🧭 Operation Modes – Auto / Manual / Test.
• 🔌 Starter Type – Fully automatic Star-Delta with interlock protection.
• 🚨 Protections – Overload, short circuit, phase failure, single phasing, phase reversal.
• 🏗️ Enclosures – CRCA powder-coated IP54 / IP65; SS optional for outdoor use.
• 🔗 Integration – Pressure Switch, Flow Switch, Fire Alarm Panel, or BMS connectivity.

🔥 Thermonic Star-Delta Panels deliver robust performance, reduced inrush current, and consistent firefighting readiness — trusted across industries and projects nationwide.
